Is This Lift Right For You?
✅ Home garages with 12' ceilings or higher
✅ Professional repair shops
✅ Passenger cars, SUVs, and light-duty trucks
✅ Customers who prefer symmetric lifting arms
✅ Full under-vehicle maintenance and repairs
✅ Buyers wanting an unobstructed workspace between columns
❌ Not recommended for garages with ceilings under 12'
❌ Not ideal for low-ceiling installations
❌ Not designed for vehicles exceeding 9,000 lbs
The Tuxedo TP9KSCX is a 9,000 lb clear-floor two-post lift designed for both professional shops and serious home garage owners. Its overhead design keeps the floor area between the columns clear while the symmetric arm configuration provides balanced lifting for a wide range of vehicles.
| Lift Model |
TP9KSCX |
| Capacity |
9,000 lbs. |
| Height Overall |
142-7/8″ |
| Width Overall w/ Power Unit |
138″ |
| Max Lift Height |
72″ |
| Width Between Columns |
113-5/8″ |
| Min. Pad Height |
4″ |
| Drive Thru Clearance |
96″ |
| Lifting Speed |
50S |
| Asymmetric / Symmetric |
Symmetric |
| Clear Floor / Floor Plate |
Clear Floor |
| Short Arm Reach – min/max |
31″-45″ |
| Long Arm Reach – min/max |
Same |
| Narrow Bay Setting |
NA |
| Max Load Per Arm |
2,050 lbs. |
| Ship Weight |
1,370 lbs |
| Power |
220V – 20 AMP – 1 PH |
