Tuxedo

Two-Post 9K Lift (TP9KACX)

Name: Two-Post 9K Lift (TP9KACX)
Brand: Tuxedo
SKU: TP9KACX
Price: 2750.00 USD
Availability: InStock

$2,750.00 USD

Sale Sold out

Quantity

FREE LOCAL PICKUP (Reidsville, NC) -- NO WAREHOUSE FEES ADDED

Lift Model	TP9KACX
Capacity	9,000 lbs.
Height Overall	142-7/8″
Width Overall w/ Power Unit	138″
Max Lift Height	72″
Width Between Columns	113-5/8″
Min. Pad Height	4″
Drive Thru Clearance	96″
Lifting Speed	50S
Asymmetric / Symmetric	Asymmetric
Clear Floor / Floor Plate	Clear Floor
Short Arm Reach – min/max	29″-41″
Long Arm Reach – min/max	37″-57″
Narrow Bay Setting	NA
Max Load Per Arm	2,250 lbs.
Ship Weight	1,370 lbs
Power	220V – 20 AMP – 1 PH

TP9KACX Lift Video: Click Here

TP9KACX Lift Manual: Click Here

TP9KAC Lift Flier: Click Here

Local Pick-up (Reidsville, NC): 12' - 16' (Open) trailer required for pick-up. Enclosed trailers will not be loaded due to risk of damage to loading ramp.

Shipping / Receiving: Offloading of the delivery truck is the responsibility of the customer. A forklift or similar vehicle is required to unload the lift. Residential delivery is an additional $150 charge by the freight carrier.

View full details
